PRODUCT DETAILS
CELLBOX™ SHIPPER FLIGHT
TECHNICAL SPECIFICATIONS
The Cellbox™ Shipper Flight, is a cell shipping CO2 incubator that has been an IATA compliance. It provides lab-like incubation conditions during transport – by road, rail, sea and even air. Our Cellbox™ is completely self-sufficient, because of an integrated rechargeable lithium-ion battery pack (4 x 99,6 Wh) and a CO2 conditioning system that relies on dry-ice sublimation.
The device is simple to use and the internal parameters can be programmed by the user. At standard incubation conditions of 37°C and 5% CO2, we guarantee an operating time of 48 hours at an ambient temperature of 23°C. Data logs of the internal conditions are continuously collected and can easily be exported to an iOS smart device with Bluetooth connectivity using our Cellbox App. By providing the ideal transport conditions, the Cellbox™ eliminates the risk of changing the biology of cell structures and maintains the high quality of your passengers.
CELLBOX APP
Constant Data Tracking and Easy Data Export
HIGHLY USER FRIENDLY
Easy To Use Software
GLOBAL CERTIFICATES
Highest Standard proven by Global Certificates
EXCEPTION MANAGEMENT
Get a Clear Inside of Your Transport
Technical Data Shipper Flight
| Cellbox™ Shipper Flight | |
|---|---|
| CO2 source | Dry ice sublimation |
| CO2 concentration (%) | 0 – 18 |
| Temperature range | 28-38°C @ 23°C ambient temperature |
| Maintains 5% CO2 environment for | + 32 hours |
| Battery maintains 37°C at RT for | + 48 hours* |
| Data logging | Reworked Cellbox App |
| Data logging interval | every 1 minute |
| CBS 21 CFR Part 11 Compliance | On request** |
| Touchscreen input | ✓ |
| Flight permit | ✓ |
| Lid opening sensor | ✓ |
| Tilt | ✓ |
| Vibration | ✓ |
| Acceleration | ✓ |
| Ambient pressure | ✓ |
| Ambient temperature | ✓ |
| GPRS tracker | On request |
| Weight (kg) | 17 |
| Power | 100 – 240 V |
| Car adapter | ✓ |
* in Cellbox Overpack@ 23°C ambient temperature
** with surcharge
THE NEW GENERATION OF
ACTIVE TEMPERATURE-CONTROLLED AND CO2 CONDITIONED SHIPPING INCUBATORS.
Cellbox™ Shipper Flight – The new generation of active temperature-controlled and CO2 conditioned shipping incubators.
Challenge the status quo and choose live cell shipping.
Traditionally, cells and other biological material have been stored and transported at low to cryogenic temperatures. However, there are applications where cryopreservation is incompatible or where cell recovery rates are unsatisfactory. Cellbox™ addresses these challenges by providing an environment where cells can be kept at user-defined incubation conditions in transit. Transit times in excess of 32 hours can be expected at an incubation temperature of 37°C and a CO2 concentration of 5%. When the shipment is handled by a specialty logistics provider, this transit period can be extended up to 48 hours and more, ensuring that your valuable cells can reach nearly any destination worldwide.
Tobias Abel – Sangamo Therapeutics France SAS
"We transported samples of CAR regulatory T cells from Nice/France to a collaboration partner in Lübeck/Germany. The cells arrived after ~36 hours of transfer in perfect condition. Cellbox allows us to transfer living samples to CROs/Collaboration partners without the need to establish a freezing process, which is especially in small scale very challenging."
Applications
ARE YOU LOOKING FOR A BETTER WAY TO TRANSPORT CELLS?
Have you explored the possibility of live cell transport? Unwanted outcomes, such as a loss of cell viability or undesired differentiation events can be avoided by transporting under highly regulated lab-like conditions. Our Cellbox™ Shipper Flight is a validated and trusted solution for shipping a wide range of cells and other cell-based material. If you are planning your next cell shipment, you are definitely in the right place. Click here to see examples of application fields where the Cellbox™ is already making a contribution.
Questions?
Questions?
Transporting your cells in a safe and efficient manner is the missing component in your biopharmaceutical jigsaw puzzle? Then get in touch and learn how the Cellbox™ can minimize your challenges and maximize your supply chain output.
Get in Touch
Senior Director Business Development & Sales Europe and Asia
